Z20004 Metal Drilling Machine:
Features:
1.Main parts: headstock, long machine bed, short machine bed, big slider, small slider, motor blades, connection piece, radial arm, drilling table, gear etc.
2. Working material: wood, soft metal(copper, aluminum etc.),acrylic, plastic etc.
All of the parts are made of metal.
Technical parameters:
1.Motor speed :20,000rpm/min(optional choice 12,000rpm/min)
2.Input voltage/current/power:12VDC/2A/24W
3. Axis Y /Z travel :30mm
4. Axis X travel :160mm
5. Collects: 1-6mm(The standard collet for this machine is two φ6 size,if need other size collet,please contact us when purchase)
6. Working table size:123*100mm
7. Working material: wood plastic, soft metal(gold, silver, copper, aluminum etc.)
8. With 0.02mm scale line ,the hand wheel increases the precision when processing.
