NUMOBAMS TZ20005MF 60W Big Power Metal Beads Machine

Name: NUMOBAMS TZ20005MF 60W Big Power Metal Beads Machine
Brand: NUMOBAMS
SKU: TZ20005MF
Price: 145.63 USD
Availability: InStock

0.0 (0 Reviews)

~~$176.52~~ $145.63

Received successfully

Coupon Code

CONTINUE SHOPPING

Description

Features:

1.Motor case and headstock are jointed. Maximum motor power is 144W by using more powerful motor. It can process beads.
2.Main parts: headstock, long machine bed, short machine bed, big slider, small slider, motor blade, gear, connection piece, vice etc. All of the parts are made of metal.

Technical parameters:

1.Motor speed :12,000rpm/min(optional choice 20,000rpm/min)

2.Input voltage/current/power:12VDC/5A/60W

3.Working material: wood, lignin plastic

4.Maximum working material size clamped by three-jaw chuck:50mm

5.The transformer has over-current protection , over-voltage protection, over-heating protection .

6.With 0.02mm scale line ,the handwheel increases the precision when processing.

7.Motor power :144W。

8.Maximum working material diameter clamped by vice:50mm

9.Between slider space ,there is plastic elastic material to adjust the precision.

10.Axis Y travel:：30mm， Axis X /Z travel ：145mm；
11. Working material: wood, plastic, acrylic, soft metal(gold, silver, copper, aluminum etc.)

12.Maximum beads diameter:20mm

13. The flank and front of the beads blade are dangerous , so people need to be guided by the professional when using it.
