TCZ20005MTF 4 Shafts CNC Milling Machine/Mach3 CNC DIY Drilling & Milling Machine

4 Shafts CNC Milling Machine

Feature:

Motor case and headstock are jointed. Motor power reaches 144W by using a powerful motor. It can machine gears with different specifications.

1.System: Mach 3(Optional Zhouyu Industrial system)

2. Machine parts: headstock, central block, motor blade, gear, cross slider, big slider, connection piece, long machine bed, short machine bed etc.

​

Technical parameters:

1.Motor speed : 12,000rpm/min

2.Input voltage/current/power:12VDC/5A/60W

3.Axis Y,Z slider travel 50mm, Axis X 145mm

Axis A=360°/200/8=0.225°

4.Collets:1-6mm

5.X.Y.Z.A stepping motor:1.5Nm, current 2A,1.8°

6.Accuracy: 0.07mm

7. 4 axis work at the same time, can process 3D surface

9. Maximum diameter of chucks: 50mm

10. Working material: lignin plastic, soft metal (gold, silver, copper, aluminum etc.)

11.Computer port: parallel interface

12.Power of controller and adaptor: Input AC110-240V, output DC12V,5A

 Processing Product:

Display Picture:

 Operation Picture:
